Forged Flanged End Globe Valve

Application : Throttling / Regulating

Features / Benefit : OS & Y Construction Renewable Seat Rings, Integral Seat  Rings, Pressure Seal Bonnet or Welded Bonnet on request for High Pressure

Ansi Class / Rating : 150#, 300#, 600#

Design Standard : BS 1873

Testing Standard : API 598, ISO 5208

F to F Standard : ASME B16.10

Size : 15 mm to 600 mm

Materials : Body : WCB, CF8, CF8M, Hast Alloy,
Super Duplex, Alloy 20 , LCB etc
Trim : 13 % Cr, Stellite etc

Ends : Flanged End, Butt Weld End

Operation : Manual, Gear, Pneumatic, Electric, etc
