Specifications & Standards
| Application | Throttling |
| Features / Benefit | OS & Y Construction Welded & Renewable Seat Rings Pressure Seal Welded Bonnet on request for High Pressure |
| Ansi Class / Rating | 150#, 300#, 600#, 800#, 1500#, 2500# |
| Design Standard | BS 5352, API 602, ISO 15761, ASME B16.34 |
| Testing Standard | API 598 |
| Size | 15 mm to 50 mm |
| Materials | Body: A105, F11, F22, LF2, F304, F304L, F316, F316L, F51, F53, F55, F347, F321, INCONEL 625, MONEL 400, HASTELLOY C-276, ALLOY 20 etc |
| Ends | Screwed End, Socket Weld End, Butt Weld End, Flange End |
| Operation | Manual |
Quality over quantity
Hand Wheel Operated
Hand wheel (manual) forged globe valves are operated by turning a robust wheel that drives a threaded stem to open or close the valve. This design allows precise control over throttling and shut‑off, making them ideal for systems where flow adjustment is needed in real time. Manufacturers typically use high-quality materials like carbon or stainless steel forgings to ensure durability and resistance to pressure and temperature variations.
Read the full storyQuality over quantity
Gear Operated
Gear-operated forged globe valves include a gearbox that reduces the required manual effort needed to move larger valve discs. A compact handwheel connected to gearing simplifies operation—turning that handwheel thus becomes easy, even for valves handling high differential pressures or large nominal diameters.
